Vaibhav Engineering
VE 3000

VE 3000

VE 3000 Truck comes with Auto Rod Changer, heavy duty Rotary Head with piston and motor and mud pumps with separate engines. It has a hole diameter of 6 to 14 inches and can go up to maximum working pressure of 4000 PSI. It comes with an updated technology hydraulic rod lifter. Rod Handling Capacity of 4.572 Mtr (15 Ft.) & (20 Ft.). The Roatryhead is Powered by Two Orbital Hydraulic Motor with a maximum speed of 40-120 RPM. The feed Cylinder is 200 MM and also there is a Hydraulic Cylinder that comes with wire rope Combination.

Read More
VE 2000A Premium Model

VE 2000A Premium Model

The VE 2000A Premium Model truck has a Hole Diameter of 6 to 14 Inches and a DTH Drilling Depth of 3000 Ft. The Deck Engine is 218 HP Ashok Leyland. The Hydraulic System Pressure has a maximum Working Pressure of 4000 Psi and comes with an updated technology Hydraulic Rod Lifter. It can be used for Water well Drilling Rig or DTH Cum Roatry. The maximum capacity of the Drilling Tower Box Type Structure is 30 Tons and a Rod Handling Capacity 4.572 Mtr (15 Ft.) & (20 Ft.). The length and width of the machine are 7470 MM and 2565 MM respectively.
Read More
VE 2000 Regular Model

VE 2000 Regular Model

Truck 1 with Compressor and Fuel

Tank Truck 2 with Hydraulic System

Compressor

Auto Rod Changer.

Read More
VE 1000A - Classic Model

VE 1000A - Classic Model

Tank Truck 2 with Hydraulic System

Compressor

Auto Rod Changer.

Read More
VE TPU

VE TPU

Lorem ipsum dolor sit amet, consectetuer adipiscing elit. Aenean commodo ligula eget dolor. Aenean massa. Cum sociis natoque penatibus et magnis dis parturient montes, nascetur ridiculus mus.

Read More
VE1000

VE1000

VE 1000 Truck comes with Auto Rod Changer, heavy duty Rotary Head with piston and motor and mud pumps with separate engines. It has a hole diameter of 6 to 14 inches and can go up to maximum working pressure of 2000-4000 PSI. It comes with an updated technology hydraulic rod lifter. The Roatryhead is Powered by Two Orbital Hydraulic Motor with a maximum speed of 40-120 RPM. The feed Cylinder is 200 MM and also there is a Hydraulic Cylinder that comes with wire rope Combination.
Read More
VE 6000

VE 6000

VE6000 Truck comes with Auto Rod Changer. It has a hole diameter of 6 to 20 inches and can go up to maximum working pressure of 5000 PSI. It comes with an updated technology hydraulic rod lifter. Rod Handling Capacity of 1500 Mtr (15 Ft.)

Read More
